DIN Lap Joint Flange yog ib hom flange nrov nyob rau hauv ob qho tib si piping thiab duct system tsim. Lub Lap Joint Flange yog siv ua ke nrog qhov kawg qhov kawg qhov twg lub flange yog hla lub stub kawg haum uas yog ces txuas mus rau tog raj los yog lwm yam haum los ntawm vuam los yog lwm yam mechanical txhais tau tias.
DIN Lap Joint Flange tsis kho thiab yog sab laug rau kev sib raug zoo nrog cov kev sib txuas nws yog txuam rau. Cov txiaj ntsig ntawm kev sib dhos no yog yog tias muaj kev sib tsoo ntau zaus lossis nrawm thiab kev sib dhos thaum lub sijhawm tu cov kav dej. Lub peev xwm los tig thiab tso lub flange them nyiaj rau txhua qhov tsis zoo ntawm lub qhov ntsia hlau thaum lub sij hawm rov ua haujlwm.
Tsis tas li ntawd, lub puab tsaig flanges tuaj yeem hloov kho tau yooj yim thiab tig los xyuas kom muaj kev sib txuas kom raug thiab ua kom cov txheej txheem tu hauv cov tshuab uas yuav tsum tau ua kom nquag plias.
Lub peev xwm los siv cov flanges uas tsis tas yuav tsum tau welds ntawm daim hlau tuaj yeem txo lub sij hawm teeb tsa thiab muab kev txuag nqi ntxiv.
Khoom Parameters
|
Txuj |
Nominal Txoj kab uas hla (mm) |
Qib Siab (LB / MPa / kg / cm²) |
Khoom siv |
|
DIN |
DN 15-DN250 |
PN10, PN16, PN25, thiab lwm yam. |
Cov pa roj carbon steel Stainless hlau |
|
GB/T 9112 ~ 9124-2010 |
DN 15-DN3000 |
PN1. 0, np42 |
Cov pa roj carbon steel Stainless hlau |
|
TS EN 1092 |
DN 15-DN3000 |
PN 2.5; PN6; PN10; PN16; PN25; PN40; PN63; PN100; PIB 160 |
Cov pa roj carbon steel Stainless hlau |
|
BS 3293, 4504, 4505 ib |
DN 15-DN3000 |
PN 2.5; PN6; PN10; PN16; PN25; PN40; PN63; PN100; PIB 160 |
Cov pa roj carbon steel Stainless hlau |
|
JIS |
DN 15-DN500 |
5K, 10K, 16K, 20K |
Cov pa roj carbon steel Stainless hlau |
|
Lus ceeb toom: 1. Rau cov ntsiab lus ntawm DIN Lap Joint Flange uas koj xav tau, koj tuaj yeem tiv tauj peb txhua lub sijhawm los muab kev daws teeb meem zoo dua rau koj; 2. Peb muaj peev xwm tsim cov flanges uas tsis yog tus qauv raws li cov duab kos los ntawm cov neeg siv khoom, thiab tseem tuaj yeem muab cov duab kos thiab suav cov flanges raws li tus qauv tsim ntawm flanges. |
|||
Daim ntawv thov
DIN lap joint flange yog dav siv hauv boiler siab hlab ntsha, roj av, tshuaj lom neeg kev lag luam, shipbuilding, kws, metallurgy, machinery, stamping luj tshib zaub mov thiab lwm yam lag luam.
Pob & Thauj
Peb yuav ua raws li cov neeg siv khoom xav tau thiab cov qauv xa tawm thoob ntiaj teb los xaiv cov khoom ntim cov ntaub ntawv thiab cov txheej txheem los xyuas kom meej cov khoom zoo yog lav ...
Kev pab cuam tom qab muag
Kev pab cuam tom qab muag zoo yog qhov kev tshaj tawm zoo tshaj plaws ua ntej kev muag khoom tom ntej, txoj hauv kev tseem ceeb los txhim kho cov neeg siv khoom txaus siab thiab kev ntseeg siab, thiab ib txoj hauv kev tseem ceeb los tsim kom muaj lub koob npe nrov ntawm tuam txhab thiab nthuav tawm cov duab lag luam. Yog li ntawd, peb muab qhov tseem ceeb rau qhov txuas no. Txhua qhov kev tsis txaus siab los ntawm cov neeg siv khoom yuav raug daws ua siab ntev.
